Small Wing Bracket shown with a 24"x6" blue reflective street blade. Wing Bracket is powder coated black.

Small Wing Bracket (WB-S08) Recommended for signs widths between 16" and 24"

Large Wing Bracket (WB-L09) Recommended for sign widths between 24"-36"

Extra Large Wing Bracket (WB-XL10) Recommended for sign widths between 36" -54"

A Large Wing Bracket shown assembled to a fluted post. The Large Wing Bracket is holding a 36"x9" street-blade.

Product Code: WB-L09

Street Blade Wing Bracket

Name: Street Blade Wing Bracket
Brand: Signature Streetscapes
SKU: WB-L09
Price: 42.00 USD
Availability: InStock

$45.50
Usually Ships within 2-6 Weeks

Shipping calculated at checkout.

Made of solid rust-free aluminum our small, large, and extra-large wing brackets are available to accommodate a variety of sign sizes. Brackets hold a flat . 080" street sign and can be mounted to our standard posts as well as walls, concrete or wood. Provide us with your application details and we can send hardware that suits your needs. Available in black powder coat finish.

[{"id":41453428867267,"title":"Large Wing Bracket","option1":"Large Wing Bracket","option2":null,"option3":null,"sku":"WB-L09","requires_shipping":true,"taxable":true,"featured_image":{"id":42879615828276,"product_id":7134182768835,"position":3,"created_at":"2023-10-19T09:32:25-04:00","updated_at":"2023-10-19T09:34:31-04:00","alt":"Large Wing Bracket (WB-L09) Recommended for sign widths between 24\"-36\"","width":1000,"height":1000,"src":"\/\/signaturestreetscapes.com\/cdn\/shop\/files\/WB-L09.jpg?v=1697722471","variant_ids":[41453428867267]},"available":true,"name":"Street Blade Wing Bracket - Large Wing Bracket","public_title":"Large Wing Bracket","options":["Large Wing Bracket"],"price":4550,"weight":2268,"compare_at_price":null,"inventory_management":null,"barcode":null,"featured_media":{"alt":"Large Wing Bracket (WB-L09) Recommended for sign widths between 24\"-36\"","id":35284041662772,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/signaturestreetscapes.com\/cdn\/shop\/files\/WB-L09.jpg?v=1697722471"}},"requires_selling_plan":false,"selling_plan_allocations":[]},{"id":41453428900035,"title":"Small Wing Bracket","option1":"Small Wing Bracket","option2":null,"option3":null,"sku":"WB-S08","requires_shipping":true,"taxable":true,"featured_image":{"id":42879615959348,"product_id":7134182768835,"position":2,"created_at":"2023-10-19T09:32:25-04:00","updated_at":"2023-10-19T09:34:31-04:00","alt":"Small Wing Bracket (WB-S08) Recommended for signs widths between 16\" and 24\"","width":1000,"height":1000,"src":"\/\/signaturestreetscapes.com\/cdn\/shop\/files\/WB-S08.jpg?v=1697722471","variant_ids":[41453428900035]},"available":true,"name":"Street Blade Wing Bracket - Small Wing Bracket","public_title":"Small Wing Bracket","options":["Small Wing Bracket"],"price":2700,"weight":2268,"compare_at_price":null,"inventory_management":null,"barcode":null,"featured_media":{"alt":"Small Wing Bracket (WB-S08) Recommended for signs widths between 16\" and 24\"","id":35284041630004,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/signaturestreetscapes.com\/cdn\/shop\/files\/WB-S08.jpg?v=1697722471"}},"requires_selling_plan":false,"selling_plan_allocations":[]},{"id":46973380428084,"title":"Extra Large Wing Bracket","option1":"Extra Large Wing Bracket","option2":null,"option3":null,"sku":"WB-XL10","requires_shipping":true,"taxable":true,"featured_image":{"id":42879615893812,"product_id":7134182768835,"position":4,"created_at":"2023-10-19T09:32:25-04:00","updated_at":"2023-10-19T09:34:31-04:00","alt":"Extra Large Wing Bracket (WB-XL10) Recommended for sign widths between 36\" -54\"","width":1000,"height":1000,"src":"\/\/signaturestreetscapes.com\/cdn\/shop\/files\/WB-XL10.jpg?v=1697722471","variant_ids":[46973380428084]},"available":true,"name":"Street Blade Wing Bracket - Extra Large Wing Bracket","public_title":"Extra Large Wing Bracket","options":["Extra Large Wing Bracket"],"price":11000,"weight":2268,"compare_at_price":null,"inventory_management":null,"barcode":"","featured_media":{"alt":"Extra Large Wing Bracket (WB-XL10) Recommended for sign widths between 36\" -54\"","id":35284041597236,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/signaturestreetscapes.com\/cdn\/shop\/files\/WB-XL10.jpg?v=1697722471"}},"requires_selling_plan":false,"selling_plan_allocations":[]}]

Signature Streetscapes Street Blade Wing Brackets

Made of solid rust-free aluminum our small, large, and extra-large wing brackets are available to accommodate a variety of sign sizes. Brackets hold a flat . 080" street sign and can be mounted to our standard posts as well as walls, concrete or wood. Provide us with your application details and we can send hardware that suits your needs. Available in black finish.

Small Wing Bracket is recommended for sign widths between : 16" - 24"

Large Wing Bracket is recommended for sign widths between : 24" - 36"

Extra Large Wing Bracket is recommended for sign widths between : 36" - 54"

Extra Large Wing Bracket

Dimensions: 36" L x 10" H x 2.5" W
Slots: .265" W x 1" D
Support is drilled and tapped with 5 each 5/16" - 18 holes opposite 9/16" non-tapped holes.
Mount on wall, concrete, wood or a post with 3/4" strapping, bolts, lag screws, or spikes
These brackets are made of solid rust free aluminum and powder coated with any of our standard color options.

Large Wing Bracket

Dimensions: 24" L x 8.75" H x 2" W
Slots: .265" W x 1" D
Support is drilled and tapped with 3 each 5/16" - 18 holes opposite 9/16" non-tapped holes.
Mount on wall, concrete, wood or a post with 3/4" strapping, bolts, lag screws, or spikes
These brackets are made of solid rust free aluminum and powder coated with any of our standard color options.

Small Wing Bracket

Dimensions: 16.5" L x 8.25" H x 2" W
Slots: .280" W x 1.25" D
Support is drilled and tapped with 2 each 5/16" - 18 holes opposite 9/16" non-tapped hole.
Mount on wall, concrete, wood, or any post with 3/4" strapping, bolts, lag screws or spikes.
These brackets are made of solid rust free aluminum and powder coated with any of our standard color options.

USDOT - New Sign Retroreflectivity Requirements

Street Sign Viewing Distance Guide - Based on USDOT-FHWA Standards for Visual Acuity

Street Blade Wing Bracket

Excellent value, easy to install, and professional look.

Robert, thank you so much for your awesome feedback! We're thrilled to hear you found the product to be a fantastic value and easy to install. If you ever need anything or have more questions, just let us know—we're here to help!

Street sign bracket replacement

Part was a perfect fit. Was installed in 10 minutes.

Hi Ronnie,

We are happy to hear this! We work hard so the customer doesnt have to! Glad everything went together well. :)
